Welding Machine (DC-220V, MMA-120A)
Name: Welding Machine (DC-220V, MMA-120A)
Type: DC-MMA, Welding Machine
Rated Input Voltage: 220V ± 10%, 50/60Hz
Rated Input Current: 32A (Approx.)
Max. Effective Input Current: 18.9A (Approx.)
Rated Input Capacity: 7.1 kVA (Approx.)
OCV: 62V (Approx.)
Continuous Welding Current: 120A (Approx.)
Rated Duty Cycle: ≥ 35% (Approx.)
Efficiency η: ≥ 85% (Approx.)
COS φ: 0.99 (Approx.)
Efficiency and Protection: High efficiency, Insulation class H, Protection class IP21S)
Weight: 7 Kg (Approx.)
Dimension: 355x142x235 mm (Approx.)
Cooling Style: Fan Cooling
Welding Machine (DC-220V, MMA-120A)
The Welding Machine using IGBT inverter technology: stable arc, small welding splash, high efficiency and energy saving. Peak current control mode, high reliability of power device. Inner-loop control, stable output and well against voltage fluctuations. Wide scope of application: suitable for J421, J422 acid electrode and J506, J507 alkaline electrode welding. Light and portable, suitable for places with high mobility, aloft working, field welding and interior decoration. Cost effective: stable performance and favorable price.
Specifications
- Name: Welding Machine (DC-220V, MMA-120A)
- Type: DC-MMA, Welding Machine
- Rated Input Voltage: 220V ± 10%, 50/60Hz
- Rated Input Current: 32A (Approx.)
- Max. Effective Input Current: 18.9A (Approx.)
- Rated Input Capacity: 7.1 kVA (Approx.)
- OCV: 62V(Approx.)
- Continuous Welding Current: 120A (Approx.)
- Rated Duty Cycle: 35% (Approx.)
- Efficiency η: ≥ 85% (Approx.)
- COS φ: 0.99 (Approx.)
- Efficiency and Protection: High efficiency, Insulation class H, Protection class IP21S
- Weight: 7 Kg (Approx.)
- Dimension: 355x142x235 mm (Approx.)
- Cooling Style: Fan Cooling
Welding Machine (DC-220V, MMA-120A) Best Features
The Welding Machine combines the best elements of its arc predecessors with superior performance and adaptability:
- Wide current range (up to 120A) – meets both moderate and heavy welding demands
- Dual-phase option -available in single or three-phase power systems
- Precision control – stepless adjustment enables fine tuning of welding current
- Efficient cooling – fan-cooled transformer structure ensures longer continuous operation
- Strong, deep welds – provides deep penetration with minimal spatter for clean results
- Durable design – copper-wound transformer and high IP/insulation ratings for reliable, long-lasting use
- Flexible electrode use – handles a broad range of rod sizes for varied applications
Welding Machine Price in Bangladesh
Welding Machine price in Bangladesh or Welding Machine Price in Bd is now affordable. Get the original products at the most affordable price only at techpalli.com to enjoy the quality with the promise of the best customer service in Bangladesh.
