Name: Plate Compactor (25 kN)

Engine: Honda GX160, Robin EY-20 or equivalent (5.0-5.5 HP) gasoline or diesel engine

Vibration Force: ~25 kN centrifugal force

Plate Size: ~ 600 × 450 mm

Operating Frequency: ~ 70 Hz

Grade Ability: ~ 25 %

Compaction Depth: Up to ~ 50 cm

Travel Speed: ~ 40 cm/s

Starting Mode: Recoil Hand start

Name: Plate Compactor (15 kN, with Water Tank)
Type: Vibratory, Single Plate, With Water Tank
Engine Type: 4-stroke, air-cooled gasoline engine
Engine Power: 5 – 5.5 HP (horsepower)
Plate Dimensions: 660 × 440 mm plate size
Working Frequency: Approximately 3600-5600 vibrations/minute
Centrifugal Force: 15-16 kN or 1.3-1.5 Ton for deep, uniform compaction
Compaction Depth: Up to 30 cm per pass
Forward Speed: Approximately 25 m/min
Fuel Tank: Approximately 3.6 L capacity for extended operation
Dry Weight: Approximately 77 kg for optimal durability and portability
Starting System: Easy pull-start with manual choke
Construction Materials: Heavy-duty steel base plate with protective guard
Applications: Suitable for compacting soil, sand, gravel, and asphalt
Compliance: Meets standard emission regulations; low-noise operation

Name: Plate Compactor (13 kN, with Water Tank)
Type: Vibratory, Single Plate, With Water Tank
Engine Type: 4-stroke, air-cooled gasoline engine
Power Output: 5.0-5.5 Hp
Plate Size: 530 mm x 500 mm (Approx)
Compaction Depth: Up to 30 cm
Centrifugal Force: 13 kN / 1.3 Ton
Vibration Frequency: 3600-5600 vpm (vibrations per minute)
Forward Speed: 25 m/min
Fuel Tank Capacity: 3.6 liters (Approx.)
Weight: 77 kg (Approx.)
Application: Soil, gravel, sand, and asphalt compaction

Name: Plate Compactor (15 kN)
Type: Vibratory, Double Plate
Power: 5–6.5 HP
Engine: Petrol (Honda GX160, Robin EY20 or Equivalent), Diesel (170F, 178F or Equivalent)
Vibration frequency: 5 600 RPM (some variants 3600 RPM–5600 RPM)
Centrifugal force: 15 kN / 1.5 Ton
Plate size: ~550 × 420 mm (approx. 55 × 42 cm)
Compaction depth: ~30 cm
Travel speed: ~40 cm/s (15–25 m/min)
Gradeability: up to 30%
Weight: 80–95 kg
Fuel type: Petrol or diesel
Features: Foldable handle, vibration‑dampening mounts, sealed belt cover, optional water tank, transport wheels

Name: Plate Compactor (20 kN)

Engine: Honda GX160, Robin EY-20 or equivalent 5.0-5.5 HP gasoline or diesel engine

Vibration Force: ~ 20 kN (kilonewtons) / 2.0 Ton ensures powerful compaction

Plate Size: ~ 600 × 480 mm

Operating Frequency: ~ 70 Hz

Grade Ability: ~ 25 %

Compaction Depth: Up to ~ 40 cm

Travel Speed: ~ 40 cm/s

Starting Mode: Hand start (some versions offer electric start)
